SHUTTLE-PUSH-UP STATION

The carrier pipe will be manufactured from a 700mm long pipe with a diameter of at least

140mm (5”) and a wall thickness of 3-4mm.

 The handle will be manufactured from industrial pipes with a diameter of at least Ø32 and a

wall thickness of 3-4 mm.

 The shuttle reclining frame will be manufactured from industrial pipes with a diameter of at

least Ø60mm and a wall thickness of 3-4mm.

 6 mm thick sheet metal clamps will be used to fix the recliners to the main body.
